Observer Pattern

The Observer Pattern is a very interesting, useful, and dynamic pattern.

Overview

  1. The main intent of the pattern is to create an event notification mechanism between objects.
  2. Think of the relationship between a publisher and a subscriber:
    • A Subscriber subscribes to a Publisher of events.
    • When an event happens the Publisher notifies all the Subscribers in its list that the event has happened

This pattern perfectly suits any process where data arrives from some input that is not available at a predefined moment, but instead arrives "at random" (for example HTTP requests, user input from peripherals, distributed databases and blockchains, etc.)

The Observer Pattern is also a key part in the well known and utilized Model-View-Controller (MVC) architectural pattern.

Motivation

The Observer pattern is one of the most useful design patterns.

Here is the motivation of the pattern as stated by GoF:

Define a one-to-many dependency between objects so that when one object changes state, all its dependents are notified and updated automatically.

Chain of Responsibility, Command, Mediator and Observer all address different ways of connecting senders and receivers of requests:

  • Chain of Responsibility is used to pass a request sequentially along a chain of receivers until one of them handles it.

  • Command is used to establish a unidirectional responsibility between a sender and a receiver.

  • Mediator (also known as Controller) removes direct connections between senders and receivers, forcing them to communicate indirectly via a mediator/controller object.

When to use

  1. Use the Observer pattern when changes to the state of one object need to be 'known' by other objects. Especially when the actual set of the other objects is either unknown initially or changes dynamically throughout the lifecycle of the application.
  2. Use it when an object or a set of objects need to 'observe' changes in other objects and need to be notified in real-time about those changes.

When not to use

  1. Because the order of notifications is potentially random, be careful about your requirements if order of notifications is important.

Pros:

  1. You can introduce new subscriber implementations without having to change the publisher's code. This is compatible with the Open/Closed Principle (OCP).
  2. It supports the principle of Loose Coupling between objects that interact with each other.
  3. You can establish relationships between objects dynamically at runtime.
  4. If you think about it, the Observer pattern is the key to reactive behaviour.

Cons:

  1. The order in which observers/subscribers are notified is potentially random.
  2. Debugging notifications can be difficult given the random nature of notifications.

Design Considerations:

  1. Look for elements in your business logic that need to be aware of state data changes.
  2. Break it down into two parts: a. The controller/receiver of the events. This will be your Publisher. b. The components that need to be aware of those changes. These will be the Subscribers.
  3. Declare the Subscriber interface which should at least have a single update or notify method.
  4. Declare the Publisher interface and define the contract for adding and removing subscribers.
  5. Create an abstract Publisher implementation with a mechanism for subscriber management and notification.
  6. Identify the state data that will need to be 'observed' and create a concrete Publisher implementation for that state. Define a way for subscribers to get access to that state.
  7. Create specific implementation of subscribers that you need.
